Fast and sharp
Together with the typical Leica, i.e. exceptional, imaging performance at all distances and apertures , the high-performance lens offers simultaneously fast and almost silent autofocus. For this, only one very light element is moved for focusing. A specially developed drive concept comprising a stepping motor and linear positioning enables very fast, almost-silent, and precise focusing without changing the overall length of the lens.
Reliable
As is the case with all other components of the SL-System, the Super-Vario-Elmar-SL 16–35 f/3.5–4.5 ASPH. is designed and constructed to meet the special demands of professional photography. Made in Germany, the robust construction of this lens and its AquaDura® lens coating make it ideal for use in even the most unfavourable conditions. Improved mount geometry and high-quality coating ensure optimum suppression of reflections and stray light within the optical system.
Ref: R03793628
Dimensions and weight
Length to bayonet mount 123 mm (without lens hood)
Largest diameter 88 mm
Weight 990 g
Field angle (diagonal, horizontal, vertical) Focal length 16mm: 105,6°/95,3°/72°
Focal length 24mm: 84,7°/74,4°/53,7°
Focal length 35mm: 64,6°/55,5°/38,7°
Optical design
Number of lenses/groups 18/12
Number of asph. surfaces / lenses 4/2
Entrance pupil position Focal length 16mm: 105,9mm
Focal length 24mm: 101,5mm
Focal length 35mm: 105,0mm
Distance setting
Working range 250mm to infinity
Smallest object field Focal length 35mm: 90 x 135 mm
Largest reproduction ratio Focal length 16mm: 1:7,7
Focal length 35mm: 1:3,7
Aperture
Setting/function Electronically controlled aperture, set using turn/push wheel on camera, including half and third values
Aperture setting range Focal length 16mm: 3,5-22
Focal length 35mm: 4,5-22
Lowest value 22
Bayonet/sensor format L-Mount, full-frame 35mm format
Filter mount E82
